PEBLAR
DUAL
MORE WITH LESS
SMARTER E AWARD 2026
Nominated for E-mobility
Two sockets
One connection
Revenue ready
More charging
less complexity
Peblar Dual is a compact, dual-socket AC charger designed to simplify commercial EV charging infrastructure.
The AFIR-ready system combines charging, payment, and connectivity in a single solution, making deployment simpler and more cost-effective, while providing a smooth user experience.
Key Features
Two sockets, one connection
Peblar Dual can charge two vehicles at once from a single mains cable
Cost and time effective installation
Lightweight 8.4kg charger for single-person installation, with a tool-safe patented back unit design for easy & accessible electrical installation.
Scalable charging infrastructure
Efficient grid utilisation, intelligent load management and staged rollout options
22kW AC charging
Powerful and fast to charge any electric vehicle, 1x 22kW / 2x 11kW
Payment terminal
Revenue-ready with in-built contactless card payments and QR code options
Large touchscreen
A user-friendly, IP54 rated accessible touchscreen with branding options
Unique Split Unit Design
Install now and commission later with a new modular backplate allowing for phased deployments and reducing time onsite
Robust and serviceable
Made in the Netherlands with an automotive
grade design and remote diagnostics
Deploy with optimised installation
More rollout, less effort.
Peblar Dual has been designed for cost and time-effective installation, enabling installers to deploy dual-socket AC charging with less site effort, lower error risk and reduced service complexity, both on individual sites and across larger roll-outs.
-
The charger weighs just 8.4kg, allowing for single-person installation
-
The tool-safe back unit ensures easy and accessible electrical installation
-
The new, patented back-unit, which is separate and reversible allows the cabling to be connected from the top or bottom of the unit
-
Fully integrated mains protections (MCB/ RCD/ SPD) means less electrical work and more time-efficient installations
Scale easily and efficiently
More charging, less infrastructure.
The Peblar Dual is designed for semi-public and commercial environments. It incorporates smart power architecture and simple cabling layouts, making it ideal for high‑density sites with limited grid capacity.
-
Maximise grid capacity and scale reliably as demand grows
-
Scale without major grid upgrades by utilising automatic phase rotation and active load balancing
-
Reduce cabling with 100A power daisy-chain, Ethernet daisy-chain and Wi-Fi Mesh
-
Implement new layouts with flat cable or bus systems up to 100A
Monetise your EV charging
More revenue, less friction.
The Peblar Dual delivers a seamless user experience with true AFIR‑ready walk‑up payment access, eliminating the friction of apps, RFID cards, and expensive external kiosks. For operators, Peblar Dual provides a revenue-ready service from day-one of operation.
-
The large, weatherproof touchscreen is user-friendly and robust
-
The in-built payment system allows for contactless card payments with PIN entry* and QR access
-
MID metering and Eichrecht‑compliant variants provide transparent, compliant billing
-
An integrated SIM with lifetime data usage is included** for reliable connectivity
* Available in future Dual versions ** Fair use policy applies
Operate with minimal management
More uptime, less intervention.
Designed and manufactured in the Netherlands, the Peblar Dual is built to withstand harsh outdoor environments and day-to-day public use. The charger is highly serviceable, with hot swap docking options for servicing and remote diagnostics.
-
Built to IATF 16949 automotive standards for lifetime reliability
-
Impact (IK10) and water (IP54) resistance (including the touchscreen display)
-
OTA updates and remote diagnostics via Connect Hub
-
Secure pedestal encloses the charger and cabling
Specifications
Key Performance |
|
|---|---|
|
Number of phases |
1x 3ph 32A / 2x 3ph 16A / 2x 1ph 32A |
|
Maximum power |
1x 22 kW / 2x 11 kW |
|
Port type |
2x Type 2 socket |
|
User interface |
Big touch screen, Socket status LED, Buzzer, Contactless Card reader |
|
Metering |
MID class B certified energy meter Eichrecht variant available |
|
Load balanacing |
Internal Load Balancing (2 sockets) Active Group Phase Balancing Automatic Phase Rotation |
|
Surge protection device |
IEC 61643-11 type 2, In=5kA TT/TN earthing system only |
|
Dimensions |
H:470 x W:291 x D:128mm |
|
Weight |
8.4kg |
Environmental |
|
|---|---|
|
Ambient Temp. |
-25/+55°C |
|
IP/IK |
IP54 / IK10 |
|
Altitude |
3000m |
Connectivity |
|
|---|---|
|
LAN |
2x Ethernet 100Mbit, integrated switch for daisy chain |
|
Mobile |
LTE CAT1 Integrated SIM with lifetime data included* Mini-SIM (2FF) |
|
WLAN |
2.4GHz Wi-Fi 6 802.11 b/g/n/ax |
|
Meter connection |
Modbus TCP/RTU |
|
Digital io |
2x in / 1x out |
Authorization Methods |
|
|---|---|
|
Card Readers |
RFID ISO14443A and B / NFC |
|
Phone/Mobile |
License free Dynamic QR code |
|
Card |
Direct card payment with pin entry (Master Card/Visa) |
Supported Protocols |
|
|---|---|
|
Vehicle Communication |
EN 61851-1 Ed4 prepared |
|
Back-end Communication |
OCPP 1.6J |
|
Group Load Balancing |
Local via web interface |
Dual Variants |
|---|
|
Standard EU (incl. UK) |
|
Shutter |
|
Eichrecht |
Accessories |
|---|
|
Peblar Dual Pedestal |
|
Peblar Dual Pedestal back-to-back (target 2027) |
|
Peblar Dual Junction Box (M40 opening) |
|
Peblar Dual Blind Cover |
|
Peblar Dual Daisy Chain Block: 2x 16mm2, Imax: 80A |
|
Peblar Dual SIM Card Holder
|
